How to use Streamlit Python with solving machine Learning Problem

Wednesday, November 6, 2024

What Is Streamlit?

Streamlit is a free and open-source framework to rapidly build and share beautiful machine learning and data science web apps.

It is a Python-based library specifically designed for machine learning engineers. Data scientists or machine learning engineers are not web developers and they're not interested in spending weeks learning to use these frameworks to build web apps. Instead, they want a tool that is easier to learn and to use, as long as it can display data and collect needed parameters for modeling.

Streamlit allows you to create a stunning-looking application with only a few lines of code.

Why should data scientists use Streamlit?

The best thing about Streamlit is that you don't even need to know the basics of web development to get started or to create your first web application. So if you're somebody who's into data science and you want to deploy your models easily, quickly, and with only a few lines of code, Streamlit is a good fit.

One of the important aspects of making an application successful is to deliver it with an effective and intuitive user interface. Many of the modern data-heavy apps face the challenge of building an effective user interface quickly, without taking complicated steps. Streamlit is a promising open-source Python library, which enables developers to build attractive user interfaces in no time.

Streamlit is the easiest way especially for people with no front-end knowledge to put their code into a web application:

No front-end (html, js, css) experience or knowledge is required.
You don't need to spend days or months to create a web app, you can create a really beautiful machine learning or data science app in only a few hours or even minutes.
It is compatible with the majority of Python libraries (e.g. pandas, matplotlib, seaborn, plotly, Keras, PyTorch, SymPy(latex)).
Less code is needed to create amazing web apps.
Data caching simplifies and speeds up computation pipelines.

How to use Streamlit

Install Streamlit

On Windows:

1. Install Anaconda and create your environment

2. Open the terminal

3. Type this command in the terminal to install Streamlit:

pip install streamlit

4. Test if the installation worked:

streamlit hello

When you type this command in the terminal, the page below should open automatically:

On macOS:

1. Install pip:

sudo easy_install pip

2. Install pipenv:

pip3 install pipenv

3. Create your environment. Open your project folder:

cd project_folder_name

4. Create a pipenv environment:

pipenv shell

5. Type this command to install Streamlit:

pip install streamlit

Test if the installation worked:

streamlit hello

On Linux:

1. Install pip:

sudo apt-get install python3-pip

2. Install pipenv:

pip3 install pipenv

3. Create your environment. Open your project folder:

cd project_folder_name

4. Create a pipenv environment:

pipenv shell

5. Type this command to install Streamlit

pip install streamlit

6. Test if the installation worked:

streamlit hello

How to run your Streamlit code

streamlit run file_name.py

Streamlit commands are easy to write and understand. With just a simple command, you are able to display texts, media, widgets, graphs, etc.

Display texts with Streamlit

In the beginning, we will see how to add text to your Streamlit app, and what the different commands are to add texts.

st.write(): This function is used to add anything to a web app, from formatted string to charts in matplotlib figure, Altair charts, plotly figure, data frame, Keras model, and others.

import streamlit as stst.write("Hello ,let's learn how to build a streamlit app together")

st.title(): This function allows you to add the title of the app. st.header(): This function is used to set header of a section. st.markdown(): This function is used to set a markdown of a section. st.subheader(): This function is used to set sub-header of a section. st.caption(): This function is used to write caption. st.code(): This function is used to set a code. st.latex(): This function is used to display mathematical expressions formatted as LaTeX.

import streamlit as st

st.title("This is the app title")

st.header("This is the header")

st.markdown("This is the markdown")

st.subheader("This is the subheader")

st.caption("This is the caption")

st.code("x = 2021")

st.latex(r''' a+a r^1+a r^2+a r^3 ''')

Display an image, video or audio file with Streamlit

You can't find functions as easy as Streamlit functions to display images, videos, and audio files. Let's take a look at how to display media with Streamlit !

st.image(): This function is used to display an image. st.audio(): This function is used to display an audio. st.video(): This function is used to display a video.

st.image("kid.jpg", caption="A kid playing")

st.audio("audio.mp3")

st.video("video.mp4")

Input widgets

Widgets are the most important user interface components. Streamlit has various widgets that allow you to bake interactivity directly into your apps with buttons, sliders, text inputs, and more.

st.checkbox(): This function returns a Boolean value. When the box is checked, it returns a True value, otherwise a False value. st.button(): This function is used to display a button widget. st.radio(): This function is used to display a radio button widget. st.selectbox(): This function is used to display a select widget. st.multiselect(): This function is used to display a multiselect widget. st.select_slider(): This function is used to display a select slider widget. st.slider(): This function is used to display a slider widget.

st.checkbox('Yes')

st.button('Click Me')

st.radio('Pick your gender', ['Male', 'Female'])

st.selectbox('Pick a fruit', ['Apple', 'Banana', 'Orange'])

st.multiselect('Choose a planet', ['Jupiter', 'Mars', 'Neptune'])

st.select_slider('Pick a mark', ['Bad', 'Good', 'Excellent'])

st.slider('Pick a number', 0, 50)

st.number_input(): This function is used to display a numeric input widget. st.text_input(): This function is used to display a text input widget. st.date_input(): This function is used to display a date input widget to choose a date. st.time_input(): This function is used to display a time input widget to choose a time. st.text_area(): This function is used to display a text input widget with more than a line text. st.file_uploader(): This function is used to display a file uploader widget. st.color_picker(): This function is used to display color picker widget to choose a color.

st.number_input('Pick a number', 0, 10)

st.text_input('Email address')

st.date_input('Traveling date')

st.time_input('School time')

st.text_area('Description')

st.file_uploader('Upload a photo')

st.color_picker('Choose your favorite color')

Display progress and status with Streamlit

Now we will see how we can add a progress bar and status messages such as error and success to our app.

st.balloons(): This function is used to display balloons for celebration. st.progress(): This function is used to display a progress bar. st.spinner(): This function is used to display a temporary waiting message during execution.

st.balloons() # Celebration balloons

st.progress(10) # Progress bar

with st.spinner('Wait for it...'):

time.sleep(10) # Simulating a process delay

st.success(): This function is used to display a success message. st.error(): This function is used to display an error message. st.warnig(): This function is used to display a warning message. st.info(): This function is used to display an informational message. st.exception(): This function is used to display an exception message.

st.success("You did it!")

st.error("Error occurred")

st.warning("This is a warning")

st.info("It's easy to build a Streamlit app")

st.exception(RuntimeError("RuntimeError exception"))

Sidebar and container

You can also create a sidebar or a container on your page to organize your app. The hierarchy and arrangement of pages on your app can have a large impact on your user experience. By organizing your content, you allow visitors to understand and navigate your site, which helps them find what they're looking for and increases the likelihood that they'll return in the future.

Sidebar

Passing an element to st.sidebar() will make this element pinned to the left, allowing users to focus on the content in your app.

But st.spinner() and st.echo() are not supported with st.sidebar.

As you see, you can create a sidebar in your app interface and put elements inside it that will make your app more organized and easier to understand.

st.sidebar.title("Sidebar Title")

st.sidebar.markdown("This is the sidebar content")

Container

st.container() is used to create an invisible container where you can put elements in order to create a useful arrangement and hierarchy.

with st.container():

st.write("This is inside the container")

Display graphs with Streamlit

Why do we need visualization?

Data visualization helps to tell stories by curating data into a format that's easier to understand, highlighting the trends and outliers. A good visualization tells a story, removing the noise from data and highlighting the useful information. However, it's not simply as easy as dressing up a graph to make it look better or slapping on the "info" part of an infographic. Effective data visualization is a delicate balancing act between form and function. The plainest graph could be too boring to draw attention or convey a powerful message, and the most stunning visualization could utterly fail at conveying the right message. The data and the visuals need to work together, and there's an art to combining great analysis with great storytelling.

Do you think giving you the data of one million points in a table/database file and asking you to provide your inferences by just seeing the data on that table is feasible? Unless you're a super human, it's not possible. This is when we make use of data visualization—it gives us a clear idea of what the information means by giving it visual context through maps or graphs. That's the power of Streamlit visualization.

st.pyplot(): This function is used to display a matplotlib.pyplot figure.

import streamlit as st

import matplotlib.pyplot as plt

import numpy as np

rand = np.random.normal(1, 2, size=20)

fig, ax = plt.subplots()

ax.hist(rand, bins=15)

st.pyplot(fig)

st.line_chart(): This function is used to display a line chart.

import streamlit as st

import pandas as pd

import numpy as np

df = pd.DataFrame(np.random.randn(10, 2), columns=['x', 'y'])

st.line_chart(df)

st.bar_chart(): This function is used to display a bar chart.

import streamlit as st

import pandas as pd

import numpy as np

df = pd.DataFrame(np.random.randn(10, 2), columns=['x', 'y'])

st.bar_chart(df)

st.area_chart(): This function is used to display an area chart.

import streamlit as st

import pandas as pd

import numpy as np

df = pd.DataFrame(np.random.randn(10, 2), columns=['x', 'y'])

st.area_chart(df)

st.altair_chart(): This function is used to display an altair chart.

import streamlit as st

import pandas as pd

import numpy as np

import altair as alt

df = pd.DataFrame(np.random.randn(500, 3), columns=['x', 'y', 'z'])

chart = alt.Chart(df).mark_circle().encode(

x='x', y='y', size='z', color='z', tooltip=['x', 'y', 'z']

)

st.altair_chart(chart, use_container_width=True)

st.graphviz_chart(): This function is used to display graph objects, which can be completed using different nodes and edges.

import streamlit as st

import graphviz

st.graphviz_chart('''

digraph {

Big_shark -> Tuna

Tuna -> Mackerel

Mackerel -> Small_fishes

Small_fishes -> Shrimp

}

''')

Display maps with Streamlit

st.map(): This function is used to display maps in the app. However, it requires the values of latitude and longitude and these values should not be null/NA.

import pandas as pd

import numpy as np

import streamlit as st

df = pd.DataFrame(

np.random.randn(500, 2) / [50, 50] + [37.76, -122.4], columns=['lat', 'lon']

)

st.map(df)

Themes

You can also choose a theme that reflects your style. Follow the steps in the GIF below:

And if you are interested in learning more about styling and themes, you can take a look at Theming.

Now, it's time to build an app together!

Build a machine learning application

In this section, I will walk you through a project I made about loan prediction.

The main profit of loans comes directly from the loan's interest. The loan companies grant a loan after an intensive process of verification and validation. However, they still don't have assurance if the applicant is able to repay the loan with no difficulties. In this tutorial, we will build a predictive model (Random Forest Classifier) to predict the loan status of an applicant. Our mission is to prepare a web app to make it available in production.

Starting with importing the necessary libraries for our app:

import streamlit as st

import pandas as pd

import numpy as np

import pickle # to load a saved model

import base64 # to handle gif encoding

In this app, we will use multiple widgets as sliders: selectbox and radio in the sidebar menu, for which we will prepare some Python functions.The example will be a simple demo that has two pages. On the homepage, it will show the data that we selected, whereas the Exploration page will allow you to visualize variables in plots, and the Prediction page will contain variables with a button named Predict that will allow you to estimate the loan status. The code below gives you a selectbox on the sidebar which allows you to select a page. The data is cached so that it does not need to reload constantly.

@st.cache is a caching mechanism that allows your app to stay performant even when loading data from the web, manipulating large datasets, or performing expensive computations.

@st.cache

def get_fvalue(val):

feature_dict = {"No": 1, "Yes": 2}

return feature_dict[val]

def get_value(val, my_dict):

return my_dict[val]

In the Home page, we will visualize: presentation picture / the dataset / histogram of applicant income and loan amount.

Note: We will use if/elif/else to switch between pages.

We will load the loan_dataset.csv in variable data that will allow us to show a few lines of it in the Home page.

if app_mode == 'Home':

st.title('Loan Prediction')

st.image('loan_image.jpg')

st.markdown('Dataset:')

data = pd.read_csv('loan_dataset.csv')

st.write(data.head())

st.bar_chart(data[['ApplicantIncome', 'LoanAmount']].head(20))

Then in the Prediction page:

if app_mode == 'Prediction':

ApplicantIncome = st.sidebar.slider('ApplicantIncome', 0, 10000, 0)

LoanAmount = st.sidebar.slider('LoanAmount in K$', 9.0, 700.0, 200.0)

# Assuming additional input features here...

# Prediction Logic

if st.button("Predict"):

loaded_model = pickle.load(open('Random_Forest.sav', 'rb'))

prediction = loaded_model.predict(np.array([ApplicantIncome, LoanAmount]).reshape(1, -1))

if prediction[0] == 0:

st.error('According to our calculations, you will not get the loan.')

else:

st.success('Congratulations! You will get the loan.')

We wrote two functions get_value(val,my_dict) and get_fvalue(val) and dictionaries as feature_dict to manipulate st.sidebar.radio() with non-numeric variables. It's optional, you can easily do something like this:

Let's see why we did that.

Note: Machine learning algorithms cannot handle categorical variables. In the dataset, I did some feature engineering. For example, the column Married has two variables 'Yes' and 'No' and I did a Label Encoding ( Take a look to better understand ) so "NO" will be equal to 1 and "Yes" to 2. The function get_fvalue(val) will easily return the value (1/2) depending what the client has chosen. Same for the function get_value(val,my_dict) . The difference between the two functions is that the first works on yes/no features and the second one is in the general case when we have multiple variables ( example: Gender ).

As we can see the variable Dependents has four categories '0','1' , '2' and '3+' and we cannot convert something like that into a numeric variable, and we have '+3' that means Dependents can take 3,4,5 ... We did a One Hot Enconding ( Take a look to better understand ) Thus , we created a sidebar radio containing the four elements and each one has a binary variable, if the client chose '0' class_0 will be equal to 1 and the others will be equal to 0.

Also we did One Hot Encoding for Property_Area that's why we created 3 variables (Rural,Urban,Semiurban) ,When Rural takes 1 the others will be equal to 0.

So we have seen both—when we label or one hot encoding our features and how to deal with it to successfully created a working Streamlit app.

data1={ 'Gender':Gender, 'Married':Married, 'Dependents':[class_0,class_1,class_2,class_3], 'Education':Education, 'ApplicantIncome':ApplicantIncome, 'CoapplicantIncome':CoapplicantIncome, 'Self Employed':Self_Employed, 'LoanAmount':LoanAmount, 'Loan_Amount_Term':Loan_Amount_Term, 'Credit_History':Credit_History, 'Property_Area':[Rural,Urban,Semiurban], } feature_list=[ApplicantIncome,CoapplicantIncome,LoanAmount,Loan_Amount_Term,Credit_History,get_value(Gender,gender_dict),get_fvalue(Married),data1['Dependents'][0],data1['Dependents'][1],data1['Dependents'][2],data1['Dependents'][3],get_value(Education,edu),get_fvalue(Self_Employed),data1['Property_Area'][0],data1['Property_Area'][1],data1['Property_Area'][2]] single_sample = np.array(feature_list).reshape(1,-1)

Now we will store our variables in a dictionary because we wrote get_value(val,my_dict) and get_fvalue(val) to deal with dictionaries. After that, the input—what the client will choose as input in our Streamlit app—will be arranged in a list named feature_list then to a numpy variable named single_sample.

Note: The inputs of features must be arranged in the same order of dataset columns (e.g. Married cannot take the input of Gender).


Finally, we will load our saved RandomForestClassifier model in loaded_model and its prediction, which is 0 or 1 (classification problem) in prediction. The .gif files will be stored in file and file_. Depending on the value of prediction, we will have two cases, "Success" or "Failed," to get a loan from the bank.

This is our Prediction page:
